Stock Code

PSW-250-03750-687

SI 3750 3000 0687 0250 T-PSW
Price on Enquiry
The PSW is a single acting piston seal comprised of a rubber fabric rein-forced sealing element and a polyacetal ring that doubles as a guide and extrusion ring.
Enquire Now
0 in Stock
Sydney, NSW
0
Melbourne, VIC
0
Newcastle, NSW
0
Brisbane, QLD
0
Hallam, VIC
0
Mackay, QLD
0
Profile: PSW Ød1: 3.000 ØD1: 3.750 Ød2: 3.508 L1: 0.687 L2: 0.250
Temp: -30°C To 100°C Speed: 0.5m/s Pressure: 400 Bar Type: S/A Piston Seals Wear Ring Diameter: 3.508 Applications(s): ["S/A Piston Seals"]
